censored

A tidymodels package for survival models - Hannah Frick

• When people hear survival analysis, they often think of situations (and data) like this.

• It’s called “survival analysis” for a reason and most examples are indeed of the category “time to death”.

• But that’s not the only context for censored data and hence survival models!

• Before I joined RStudio, I worked at a data science consultancy and one of my colleagues chatted to me about his latest project.

• A newspaper company wanted to know how many copies they should deliver to their various outlets and he was musing that
  • if there are copies left at the end of the day they would know how many were taken
  • if there none left, they would still know how many were taking but they would not know how many more would have been taking if they hadn’t run out
  • in that case, their observation of the demand for the newspaper is censored, capped at the number of papers they provided
• so the stats nerd in me grinned and suggested to look at survival analysis
• and now I get to tell you all about it too!

For censored data,

i.e., data with two aspects

• “how long until?”
• “has it happened yet?”

use survival analysis

to take both aspects into account!

• if you have data of this format
  • where you are observing something “until an event” - be that “time until death” or “newspapers taken until demand saturation”
  • and you may or may not actually observe that event
• use survival analysis
  • designed to take both aspects into account
  • regular regression models on that time, or newspaper demand, without the event indicator: treating obs as complete
  • if you are dropping all censored observations: treating at missing

We’re extending support for

survival analysis in tidymodels

• extending support in tidymodels
• first milestone are the models
• abundance of riches in models and interfaces
• effective, safe, and ergonomic
• part of that: consistent interface

Consistency in

• how you specify and fit models
• how you predict and what you get back

• In the tidymodels framework, this aspect is captured in parsnip package
• it’s designed to give you consistency

Consistency in

• how you specify and fit survival models
• how you predict and what you get back

so censored is a parsnip extension package and I’ll be talking about how these design principles are playing out for survival models

Specify and fit!

parsnip model specification

rand_forest() %>%
  set_engine("ranger") %>%
  set_mode("regression")
#> Random Forest Model Specification (regression)
#>
#> Computational engine: ranger

Additions for survival models

• New model type proportional_hazards()

• New mode "censored regression"

• New engines for
  • Parametric models
  • Semi-parametric models
  • Tree-based models

• Formula interface for all models, including stratification

Cetaceans data

Adapted from Tidy Tuesday 2018-38:

cetaceans
#> # A tibble: 1,313 × 6
#>      age event species    sex   transfers born_in_captivity
#>    <dbl> <dbl> <fct>      <fct>     <int> <lgl>
#>  1    28     0 Bottlenose F             0 TRUE
#>  2    44     0 Bottlenose F             0 TRUE
#>  3    39     0 Bottlenose M            13 TRUE
#>  4    38     0 Bottlenose F             1 TRUE
#>  5    38     0 Bottlenose M             2 TRUE
#>  6    37     0 Bottlenose F             2 TRUE
#>  7    36     0 Bottlenose M             2 TRUE
#>  8    36     0 Bottlenose F             2 TRUE
#>  9    35     0 Bottlenose M             3 TRUE
#> 10    34     0 Bottlenose F             4 TRUE
#> # … with 1,303 more rows

• dolphins and whales living in captivity in the USA
• point out response

Proportional hazards model

library(censored)

mod_survival_censored <-
  proportional_hazards()

Proportional hazards model

library(censored)

mod_survival_censored <-
  proportional_hazards() %>%
  set_engine("survival")

Proportional hazards model

library(censored)

mod_survival_censored <-
  proportional_hazards() %>%
  set_engine("survival") %>%
  set_mode("censored regression")

Proportional hazards model

library(censored)

mod_survival_censored <-
  proportional_hazards() %>%
  set_engine("survival") %>%
  set_mode("censored regression") %>%
  fit(
    Surv(age, event) ~ species + sex + transfers,
    data = cetaceans
  )

Proportional hazards model

library(censored)

mod_survival_censored <-
  proportional_hazards() %>%
  set_engine("survival") %>%
  set_mode("censored regression") %>%
  fit(
    Surv(age, event) ~ species + sex + transfers +
      strata(born_in_captivity),
    data = cetaceans
  )

Proportional hazards model

library(survival)

mod_survival <- coxph(
  Surv(age, event) ~ species + sex + transfers + strata(born_in_captivity),
  data = cetaceans
)

Switching to penalized model

library(survival)

mod_survival <- coxph(
  Surv(age, event) ~ species + sex +
    transfers + strata(born_in_captivity),
  data = cetaceans
)

Switching to penalized model

library(survival)

mod_survival <- coxph(
  Surv(age, event) ~ species + sex +
    transfers + strata(born_in_captivity),
  data = cetaceans
)

library(glmnet)

x <- model.matrix(~ species + sex +
                    transfers,
                  data = cetaceans)[, -1]
y <- Surv(cetaceans$age, cetaceans$event)
y_strata <- glmnet::stratifySurv(
  y, strata = cetaceans$born_in_captivity
)

mod_glmnet <- glmnet(x, y_strata,
                     family = "cox",
                     lambda = 0.1)

Switching via censored

mod_survival_censored <-
  proportional_hazards() %>%
  set_engine("survival") %>%
  set_mode("censored regression") %>%
  fit(
    Surv(age, event) ~ species + sex +
      transfers +
      strata(born_in_captivity),
    data = cetaceans
  )

mod_glmnet_censored <-
  proportional_hazards(penalty = 0.1) %>%
  set_engine("glmnet") %>%
  set_mode("censored regression") %>%
  fit(
    Surv(age, event) ~ species + sex +
      transfers +
      strata(born_in_captivity),
    data = cetaceans
  )

Switching via censored

mod_survival_censored <-
  proportional_hazards() %>%
  set_engine("survival") %>%
  set_mode("censored regression") %>%
  fit(
    Surv(age, event) ~ species + sex +
      transfers +
      strata(born_in_captivity),
    data = cetaceans
  )

mod_glmnet_censored <-
  proportional_hazards(penalty = 0.1) %>%
  set_engine("glmnet") %>%
  set_mode("censored regression") %>%
  fit(
    Surv(age, event) ~ species + sex +
      transfers +
      strata(born_in_captivity),
    data = cetaceans
  )

Switching via censored

mod_survival_censored <-
  proportional_hazards() %>%
  set_engine("survival") %>%
  set_mode("censored regression") %>%
  fit(
    Surv(age, event) ~ species + sex +
      transfers +
      strata(born_in_captivity),
    data = cetaceans
  )

mod_glmnet_censored <-
  proportional_hazards(penalty = 0.1) %>%
  set_engine("glmnet") %>%
  set_mode("censored regression") %>%
  fit(
    Surv(age, event) ~ species + sex +
      transfers +
      strata(born_in_captivity),
    data = cetaceans
  )

More models, same syntax

mod_mboost_censored <-
  boost_tree() %>%
  set_engine("mboost") %>%
  set_mode("censored regression") %>%
  fit(
    Surv(age, event) ~ species + sex + transfers,
    data = cetaceans
  )

Available in censored

All for the mode "censored regression".

model	engine
bag_tree()	rpart
boost_tree()	mboost
decision_tree()	rpart
decision_tree()	partykit
proportional_hazards()	survival
proportional_hazards()	glmnet
rand_forest()	partykit
survival_reg()	survival
survival_reg()	flexsurv

Predict!

tidymodels prediction guarantee

• The predictions are always inside a tibble.
• The column names and types are unsurprising and predictable.
• The number of rows in new_data and the output are the same.

that also applies to predictions in censored

what’s new: additional prediction types!

First up: survival time

Survival time

cetaceans_pred <- cetaceans[1:3,]
cetaceans_pred$species[1] <- NA

predict(
  mod_survival_censored,
  new_data = cetaceans_pred,
  type = "time"
)
#> # A tibble: 3 × 1
#>   .pred_time
#>        <dbl>
#> 1       NA
#> 2       32.2
#> 3       59.3

Survival probability

pred_survival_censored <- predict(
  mod_survival_censored,
  new_data = cetaceans_pred,
  type = "survival",
  time = c(10, 15, 20, 40)
)

pred_survival_censored
#> # A tibble: 3 × 1
#>   .pred
#>   <list>
#> 1 <tibble [4 × 2]>
#> 2 <tibble [4 × 2]>
#> 3 <tibble [4 × 2]>

• another new prediction type "survival"
• need to specify at which time point we want to predict
• still 3 rows

Survival probability

pred_survival_censored$.pred[[1]]
#> # A tibble: 4 × 2
#>   .time .pred_survival
#>   <dbl>          <dbl>
#> 1    10             NA
#> 2    15             NA
#> 3    20             NA
#> 4    40             NA

Survival probability

pred_survival_censored$.pred[[2]]
#> # A tibble: 4 × 2
#>   .time .pred_survival
#>   <dbl>          <dbl>
#> 1    10          0.748
#> 2    15          0.660
#> 3    20          0.584
#> 4    40          0.385

Approximation the survival curve

predict(
  mod_mboost_censored,
  new_data = cetaceans[2:3,],
  type = "survival",
  time = 1:80
) %>%
  mutate(id = factor(2:3)) %>%
  tidyr::unnest(cols = .pred)
#> # A tibble: 160 × 3
#>    .time .pred_survival id
#>    <int>          <dbl> <fct>
#>  1     1          1     2
#>  2     2          0.981 2
#>  3     3          0.957 2
#>  4     4          0.932 2
#>  5     5          0.901 2
#>  6     6          0.869 2
#>  7     7          0.843 2
#>  8     8          0.802 2
#>  9     9          0.776 2
#> 10    10          0.752 2
#> # … with 150 more rows

Approximation the survival curve

predict(
  mod_mboost_censored,
  new_data = cetaceans[2:3,],
  type = "survival",
  time = 1:80
) %>%
  mutate(id = factor(2:3)) %>%
  tidyr::unnest(cols = .pred) %>%
  ggplot(
    aes(x = .time, y = .pred_survival,
        col = id)
  ) +
  geom_step() +
  theme_bw() +
  theme(legend.position = "top")

Prediction types in censored

• For all models: "time" and "survival"
• Depending on the engine: "hazard", "quantile", "linear_pred"

you don’t have to do your own

• data prep for matrix interface
• padding of results for data with NA
• transformation from survival curve to survival probabilities at any time point

A consistent interface to

survival models

censored.tidymodels.org

• consistency in how you specify and fit
• consistency in how you predict and what you get back
• please try it out and give us feedback
